板框壓濾機壓緊、進料、洗滌或干燥、卸料操作詳細講解。正如大家所了解的，板框壓濾機的過濾面積大，流量大，適用范圍大，所以在制藥、化工、食品等行業有廣泛用途，應用在制藥廠針劑藥液之過濾，效果甚佳。那么板框壓濾機工作的四部曲你了解嗎？下面就為大家介紹一下板框壓濾機工作的四部曲。
現在板框壓濾機設備在工作運行時，都會經歷壓緊、進料、洗滌或干燥、卸料等四個步驟。簡稱板框壓濾機工作四部曲。
1.壓緊
板框壓濾機事先對整機檢查，包括濾布、電源是否正常，注意要打開排出閥。在按下“啟動”按鈕。這時油泵開始工作，然后活塞推動壓緊板壓緊，當慮室的壓力達到設計點時，液壓器就會自動暫停工作。當隨后的工作中，壓力減小，不能滿足正常工作時，液壓系統會自動開啟。
2.進料
當板框壓濾機壓緊后，即可進行進料操作：開啟進料泵，并緩慢開啟進料閥門，進料壓力逐漸升高至正常壓力。這時觀察板框壓濾機出液情況和濾板間的滲漏情況，過濾一段時間后板框壓濾機出液孔出液量逐漸減少，這時說明濾室內濾渣正在逐漸充滿，當出液口不出液或只有很少量液體時，證明濾室內濾渣已經完全充滿形成濾餅。如需要對濾餅進洗滌或風干操作，即可隨后進行，如不需要洗滌或風干操作即可進行卸餅操作。
3.洗滌或風干
板框壓濾機濾餅充滿后，關停進料泵和進料閥門。開起洗滌泵或空壓機，緩慢開啟進洗液或進風閥門，對濾餅進行洗滌或風干。操作完成后，關閉洗液泵或空壓機及其閥門，即可進行卸餅操作。
4.卸餅
這過程是先關閉進料閥，進風道，然后板框壓濾機推板就會緩慢的退回，減小對濾板的壓力，甚至會隨著活塞桿退回到適當額度位置，在取出一塊一塊的濾板，將慮餅從濾板卸下，在卸除過程中，注意對濾布的保護，防止濾渣夾在密封面上影響密封性能，產生滲漏現象。現在板框壓濾機設備有人工卸料和自動卸料兩種方式。
這四步是板框壓濾機工作的不可少的，但由于科技的發展，有時過濾和吹風干燥是同時進行的，所以有的設備不會逐步進行，從而提高效率。
The plate and frame filter press is pressed, fed, washed or dried, and the unloading operation is explained in detail. As we all know, the plate and frame filter press has a large filtration area, a large flow rate, and a wide application range. Therefore, it has a wide range of applications in the pharmaceutical, chemical, food and other industries, and is applied to the filtration of pharmaceutical injections in pharmaceutical factories, and the effect is very good. So what do you know about the four-part work of the plate and frame filter press? Here is a brief introduction to the four songs of the plate and frame filter press.
Now, the frame and frame filter press equipment will undergo four steps of pressing, feeding, washing or drying, and unloading during operation. Referred to as the plate frame filter press work four songs.
Press tight
The plate and frame filter press checks the whole machine in advance, including the filter cloth and the power supply. Pay attention to open the discharge valve. Press the "Start" button. At this point, the oil pump starts to work, then the piston pushes the compression plate to compress, and when the pressure of the chamber reaches the design point, the hydraulic device automatically stops working. In the subsequent work, when the pressure is reduced and the normal operation is not satisfied, the hydraulic system will automatically open.
2. Feeding
When the plate and frame filter press is pressed, the feeding operation can be performed: the feed pump is turned on, and the feed valve is slowly opened, and the feed pressure is gradually increased to the normal pressure. At this time, observe the liquid out of the plate filter press and the leakage between the filter plates. After filtering for a period of time, the liquid output from the filter press of the plate frame filter is gradually reduced. At this time, the filter residue in the filter chamber is gradually filling up. When the liquid port is not discharged or there is only a small amount of liquid, it is proved that the filter residue in the filter chamber is completely filled to form a filter cake. If the filter cake needs to be washed or air-dried, it can be carried out subsequently, and the unloading operation can be carried out without washing or air drying.
3. Wash or air dry
After the plate filter press filter is full, the feed pump and feed valve are closed. Open the washing pump or air compressor, slowly open the washing liquid or air inlet valve, and wash or air dry the filter cake. After the operation is completed, the washing machine or the air compressor and its valves are closed, and the unloading operation can be performed.
4. Unloading cake
This process is to close the feed valve, enter the air duct, and then the plate frame filter press will slowly retract, reduce the pressure on the filter plate, and even take the piston rod back to the appropriate amount of position, take out a piece A filter plate removes the cake from the filter plate. During the removal process, pay attention to the protection of the filter cloth to prevent the filter residue from being caught on the sealing surface to affect the sealing performance and cause leakage. Now the frame and frame filter press equipment has two methods: manual unloading and automatic unloading.
These four steps are indispensable for the operation of the plate and frame filter press, but due to the development of technology, sometimes the filtration and the blowing and drying are carried out at the same time, so some equipment will not be gradually carried out, thereby improving the efficiency.
